Motor Number

6 motors (accurate of fiber alignment: 0.05um)

Splicing Time

6S

Heating Time

15S, can be customized according to the external environment

Applicable Fibers

single-mode fiber (SMF/G.652, BIF/G.657); suitable for single mode, multi-mode, bare fiber, tail fiber, drop cable, jumper, invisible optical fiber

Cladding Diameter

80~150um

Splicing Loss

0.02dB (SM), 0.01dB (MM), 0.04dB (DS), 0.04dB (NZDS)

Splicing Mode

automatic focusing core alignment, conventional/high precision welding

Splicing Method

automatic, semi-automatic, manually

Fiber Cleaver

high precision delay return electric one-step fiber cleaver

Fiber Holder

3-in-1 fiber holder, no need to change, suitable for single/multi-mode, multi-core cable,  250um/900um/2mm/3mm/2*3mm flat drop cable

VFL

the machine comes with power: 15mW, 2Hz flashing and steady on mode

OPM

wavelength: 850/1300/1310/1490/1550/1625/980/1270/1577/1650nm; measurement range: -50~+30dBm; absolute error: <0.3dB (-50dBm~+3dBm range)

Battery Capacity

7800mAh large capacity lithium battery charging time≤3.5 hours; It can continuously weld and heat about 240 cores

Magnification

320x (X or Y axis single display), 200x (X and Y axis dual display)

Fiber Diameter

cladding diameter: 80~150um, coating diameter: 100~1000um

Fiber Cleave Length

coating less than 250um diameter: 8~16mm;   coating between 250~1000um: 16mm

Tension Test

standard 2N

Heat Shrink Tube

25/40/50/60mm

Screen

5 inch TFT color display

Boot Time

1s, boot can enter the working mode

Data Storage

unlimited, machine storage: 1,000 groups, the excess part can be stored in the server, which can export data.

Wireless Communication

based on Bluetooth 4.2 protocol standard, working band: 2.4GHz, maximum transmission range: 60m

Software Upgrade

mobile phone APP internet update, enable Bluetooth synchronization upgrade machine software

Management Function

the machine owner can be bound as the highest authority, and can remotely view the welding records, welding time, loss, etc. Through the mobile phone APP. The number of welding times or working time of the machine can be set. The manager can effectively manage a single or multiple machines.

Return Loss

better than 60dB

Protection

waterproof, dustproof and shock-resistant

Power Supply

input: 100～240VAC 50/60Hz, output: 13.5VDC/4.8A, the current power mode can be identified, real-time monitoring of current battery level

Operation Conditions

-15～+50℃, 0～95%RH (humidity), 0～5000m (altitude), max. Wind speed: ≤15m/s
